An alternative to the renowned Dyneema® brand of rope. OX Fibre provides a cost effective, high performance solution for high load applications.
In terms of break load and price point OX10, has been developed to compete with the mainstream winch line market. This product has been a popular choice within the 4x4 winching market and can be manufactured to include a spliced eye with any additional hardware.
Although OX10 has the lowest break load in the OX Fibre family, the rope can still compete with comparable products from the UKs leading rope manufactures.
** THIS PRODUCT IS OFFERED PER 100 METRE COIL **
Features & BENEFITS
• 15 x Stronger than steel wire
• Easy to splice
• High UV resistance
• Extremely high strength to weight ratio
Note: supplied in Grey Colour Finish as standard
Applications
• Winch Rope
• Emergency TowKit
• Lifting
| Specifications | Core |
| Construction | 12 strand |
| Elongation | 3% |
| Colour | Grey |
| Floats | Yes |
| Melting point |
140˚C |
|
Dia. (mm) |
Weight (kg/100) | MBL (kgs) |
| 6 | 3,000 | |
| 8 | 5,000 | |
| 10 | 8,000 | |
| 12 | 10,600 | |
| 12 | 12,100 |
Data sheet
An alternative to the renowned Dyneema® brand of rope. OX Fibre provides a cost effective, high performance solution for high load applications.
In terms of break load and price point OX10, has been developed to compete with the mainstream winch line market. This product has been a popular choice within the 4x4 winching market and can be manufactured to include a spliced eye with any additional hardware.
Although OX10 has the lowest break load in the OX Fibre family, the rope can still compete with comparable products from the UKs leading rope manufactures.
** THIS PRODUCT IS OFFERED PER 100 METRE COIL **
Features & BENEFITS
• 15 x Stronger than steel wire
• Easy to splice
• High UV resistance
• Extremely high strength to weight ratio
Note: supplied in Grey Colour Finish as standard
Applications
• Winch Rope
• Emergency TowKit
• Lifting
| Specifications | Core |
| Construction | 12 strand |
| Elongation | 3% |
| Colour | Grey |
| Floats | Yes |
| Melting point |
140˚C |
|
Dia. (mm) |
Weight (kg/100) | MBL (kgs) |
| 6 | 3,000 | |
| 8 | 5,000 | |
| 10 | 8,000 | |
| 12 | 10,600 | |
| 12 | 12,100 |
Data sheet
